Applications

• Check percentage of Carbon Content in Plastic material or finished products.

STANDARD:

• Capable to measure carbon black content in plastic products as per ASTM D 1603, IS 2530

Furnace : Tube type furnace:

• Heater-thermocouple assembly and very smooth rise of heat with highly precise temperature control ,
• 1500 Watts heating element wounded on ceramic tube
• Micro processor based double display PID controller with resolution of 1.0 °C accuracy of ± 1° centigrade
• Tube Furnace (32 x 300) or equiv.
• Temp :800c
• Timer: Micro processor based double display digital timer available at optional Up to 999.9 Seconds / Minutes
• Insulation :100mm thick triple layer ceramic wool insulation
• Power: 230V AC, Single phase, 50Hz

CBC ALL ACCESSORIES

• Quartz tube :
• Ceramic boat: 20 number
• Gas washing bottle with trap head-500 ML
• M.S. fabricated stand set
• Rubber tube
• Desiccators with porcelain plate
• Boat pulling rod-
• Test Chemicals
