FLOW TABLE-IS: 9103.1999

Material : M.S /S.S

The apparatus consists of a 700 mm square wooden top plate lined with a thin metal sheet, as shown in Figure. The plate is hinged on one end to a base, while on the other end, clips allow the plate to be lifted a vertical distance of 40 mm. Etched into the metal sheet are two perpendicular lines that cross in the center of the plate and a 200 mm circle concentric with the center of the plate. The frustum of a cone used to mold the concrete is shorter than the slump cone, with a top diameter of 130 mm and with a bottom diameter and height of 200 mm.
